| Dimensions |
| Max Working Height | | 16.7 m |
| Max Platform Height | | 14.7 m |
| Platform Size | | 1.83×0.76 m |
| Max. Horizontal Outreach | | 8.1 m |
| Max. Crossing Height | | 8.25 m |
| Platform Rotation | | ±90° |
| Turntable Rotation | | 355° |
| Overall Length(stowed) | | 6.72 m |
| Overall Width(stowed) | | 2.28 m |
| Overall Height(stowed) | 2.47 m |
| Wheel Base | 2.40 m |
| Ground Clearance | 0.40 m |
| Performance |
| Lift Capacity | 230 kg |
| Turning Radius(Inside/outside) | 1.87 m/4.8 m |
| Drive Speed-stowed | 4.2 km/h |
| Drive Speed-raised | 0.8 km/h |
| Gradeability | 45% |
| The Max. Working Slope | 5° |
| Tyre | 33×12-20 |
| Power |
| Fuel Tank | 100 L |
| Hydrulic Tank | 110L |
| Engine | 36Kw@2400rmp |
| Control Voltage | 12V |
| Walking and Steering | 4WDx 2WS/4WDx4WS |
| Weight |
| Total Weight | 7,500 kg |
